Profile 20x20 R90 mini, natural

SP2070N6000

Application

Universal applications. For aesthetic designs.

Scope of delivery

The delivery takes place as a 6 meter profile.
Length 6000mm
Width 20mm
Height 20mm
Weight 2.9kg
Area 1.760cm2
Ix 0.600cm4
Iy 0.600cm4
Wx 0.550cm3
Wy 0.550cm3
eClass Id 35070290
Customs tariff number 76042990
N
mm

Gravity g = 9.81 m/s2
Modulus of elasticity E = 70 kN/mm2
Ix = 0.600 cm4
Iy = 0.600 cm4
m/Meter = 0.478 kg
f = x mm
f1: Bending with self-weight
f2: Bending through influencing force [N]
f3: Resulting deflection
On two stilts, distributed load
  f1 f2 f3
about the x-axis 0 0 0
about the y-axis 0 0 0
f =  5 • F • l3
384 • E • I
Fixed one-sided, pointloading
  f1 f2 f3
about the x-axis 0 0 0
about the y-axis 0 0 0
f =  F • l3
3 • E • I
On two stilts, pointloading
  f1 f2 f3
about the x-axis 0 0 0
about the y-axis 0 0 0
f =  F • l3
48 • E • I
Fixed two-sided, pointloading
  f1 f2 f3
about the x-axis 0 0 0
about the y-axis 0 0 0
f =  F • l3
192 • E • I
