C-Track 40x57/280/8/C40/57
SL4000N
Application
C-tracks with plasic rollers. C-tracks require no lubrication and are a low cost alternative to linear actuators series 16.
Standard Delivery:
complete linear actuator inclusive track profile and carriage, pulley assembly with customer-specific motor connection.
Optional:
proximity and end of stroke switches, end stops, motor coupling, motors, energy cable
Carriage Options:
Carriage lengths of up to 2.3m are available. For high load systems it may be advisable to add further rollers. By having a combination of guidance and flat faced rollers the permissible actuator loading values may be increased.
Standard Delivery:
complete linear actuator inclusive track profile and carriage, pulley assembly with customer-specific motor connection.
Optional:
proximity and end of stroke switches, end stops, motor coupling, motors, energy cable
Carriage Options:
Carriage lengths of up to 2.3m are available. For high load systems it may be advisable to add further rollers. By having a combination of guidance and flat faced rollers the permissible actuator loading values may be increased.
Scope of delivery
Complete linear axis including guide profile and carriage.
| Weight | 0.8kg |
| Area | 3.040cm2 |
| Ix | 2.830cm4 |
| Iy | 3.750cm4 |
| Wx | 1.660cm3 |
| Wy | 2.500cm3 |
| eClass Id | 23309090 |
| N | |
| mm | |
| Gravity g = | 9.81 m/s2 |
| Modulus of elasticity E = | 70 kN/mm2 |
| Ix = | 2.830 cm4 |
| Iy = | 3.750 cm4 |
| m/Meter = | 0.823 kg |
| f = | x mm |
| f1: | Bending with self-weight |
| f2: | Bending through influencing force [N] |
| f3: | Resulting deflection |
On two stilts, distributed load
| f1 | f2 | f3 | |
|---|---|---|---|
| about the x-axis | 0 | 0 | 0 |
| about the y-axis | 0 | 0 | 0 |
| f = | 5 • F • l3 |
| 384 • E • I |
Fixed one-sided, pointloading
| f1 | f2 | f3 | |
|---|---|---|---|
| about the x-axis | 0 | 0 | 0 |
| about the y-axis | 0 | 0 | 0 |
| f = | F • l3 |
| 3 • E • I |
On two stilts, pointloading
| f1 | f2 | f3 | |
|---|---|---|---|
| about the x-axis | 0 | 0 | 0 |
| about the y-axis | 0 | 0 | 0 |
| f = | F • l3 |
| 48 • E • I |
Fixed two-sided, pointloading
| f1 | f2 | f3 | |
|---|---|---|---|
| about the x-axis | 0 | 0 | 0 |
| about the y-axis | 0 | 0 | 0 |
| f = | F • l3 |
| 192 • E • I |
